Parts for Shimano TIAGRA 30W LRS (2001) reel
PARTS-Ti30WLRS
Find the part you need on the exploded view of the Shimano TIAGRA 30W LRS (2001) reel, then order it directly from the list of available parts below.
Description
Identify the spare part(s) of the reel you need, then add them to the cart from the list of available spare parts located below the exploded view of the reel.
Product Details
Shimano
PARTS-Ti30WLRS
Data sheet
- Type
- Trolling
- Series
- TIAGRA
- Size
- 30
- Model
- TI30WLRS
- Generation
- 2001
Available parts for this reel
| Old reference | Reference | Price (Tax Excl.) | |
|---|---|---|---|
| TT 0002 A, TGT 0973 |
10QUC
HANDLE BOLT PLATE |
€0.80 |
|
| TT 0040 A, TGT 0020, TLD 0096 |
1052C
CONED DISC SPRING |
€0.80 |
|
| TT 0042 A, TGT 0828 |
104L7
BEARING THRUST WASHER |
€0.80 |
|
| TT 0091, TGT 0969 |
109XD
PUSH BUTTON SHIELD |
€0.80 |
|
| TT 0092, TGT 0971 |
10LZ9
HANDLE BOLT PLATE SCREW |
€0.80 |
|
| TT 0093, TGT 0970 |
10PWH
SLIDE PLATE SPRING |
€0.80 |
|
| TT 0094, TGT 0972 |
109XC
SLIDE PLATE |
€0.80 |
|
| TT 0107, TGT 0995 |
109VM
DRIVE SHAFT SPRING B |
€0.80 |
|
| TT 0148, TGT 0975 |
106XL
HANDLE BOLT |
€0.80 |
Out-of-Stock
|
| TT 0206, TGT 0990 |
10D61
FRICTION WASHER (C) |
€0.80 |
|
| TT 0209, TGT 0993 |
10KXH
GEAR SELECT CROSS BAR |
€12.00 |
Out-of-Stock
|
| TT 0210, TGT 0994 |
10KXL
CROSS BAR STOP |
€4.00 |
Last items in stock
|
| TT 0211, TGT 0996 |
10KXQ
DRIVE SHAFT SPRING |
€0.80 |
|
| TT 0212, TGT 0997 |
10D5B
FRICTION WASHER (A) |
€0.80 |
Out-of-Stock
|
| TT 0213, TGT 1572 |
10FCD
DRIVE SHAFT SCREW |
€4.00 |
Last items in stock
|
| TT 0276 |
10F1S
CROSS PIN SUPPORT SPRING |
€0.80 |
|
| TT 0343, TGT 0968 |
10PHN
PUSH BUTTON SHIELD SCREW TO TT0873 |
€0.80 |
Out-of-Stock
|
| TT 0424 |
10LZ5
LEFT SIDE PLATE SCREW |
€0.80 |
|
| TT 0470 |
10MJ4
WRENCH |
€4.00 |
Out-of-Stock
|
| TT 0472 |
TT0472
Push “Low” Button Shaft |
€0.80 |
Out-of-Stock
|
| TT 0473 |
TT0473
Handle Assembly |
€0.80 |
Out-of-Stock
|
| TT 0474 |
10KZQ
DRIVE SHAFT SHIELD |
€4.00 |
Last items in stock
|
| TT 0475 |
107QW
DRIVE SHAFT THRUST WASHER |
€0.80 |
|
| TT 0476 |
105UA
BEARING SPACER |
€0.80 |
Last items in stock
|
| TT 0477 |
108H5
01TI30PRE-PRGRM DIAL |
€4.00 |
Out-of-Stock
|
| TT 0478 |
10K06
FRICTION SHOE SPRING |
€0.80 |
|
| TT 0479, RD 6077 |
1035W
DIAL CLICK SHOE |
€0.80 |
|
| TT 0480 |
10J1W
DIAL CLICK |
€0.80 |
|
| TT 0481 |
TT0481
Cover Screws |
€0.80 |
Out-of-Stock
|
| TT 0482 |
10BHM
LEVER HUB COVER |
€9.00 |
Last items in stock
|
| TT 0483 |
109RR
01TI-30 DIAL WASHER |
€0.80 |
Out-of-Stock
|
| TT 0484 |
105NG
E LOCK |
€0.80 |
|
| TT 0485 |
109RQ
01TI-30 LEVER THRUST RING (B) |
€0.80 |
|
| TT 0486 |
TT0486
Drag Control Lever |
€0.80 |
Out-of-Stock
|
| TT 0487 |
109RP
01TI-30 LEVER THRUST RING (A) |
€0.80 |
|
| TT 0488 |
TT0488
Quadrant Anchor Bolts |
€0.80 |
Out-of-Stock
|
| TT 0489 |
TT0489
Lever Quadrant |
€0.80 |
Out-of-Stock
|
| TT 0490 |
1059Y
SPACER |
€0.80 |
Out-of-Stock
|
| TT 0491, TT 0811 |
108FY
01TI30 SA LVRASY SUS |
€0.80 |
|
| TT 0492 |
10EZS
PLUNGER CROSS PIN (B) |
€0.80 |
|
| TT 0493 |
10EZM
PLUNGER CROSS PINSUPPORT |
€0.80 |
|
| TT 0494 |
TT0494
Strike Stop |
€0.80 |
Out-of-Stock
|
| TT 0495 |
TT0495
Right Side Plate (B) |
€0.80 |
Out-of-Stock
|
| TT 0496 |
TT0496
Free Spool Detent |
€0.80 |
Out-of-Stock
|
| TT 0497 |
103H4
DRIVE SHAFT HOLDER SCREW |
€0.80 |
Out-of-Stock
|
| TT 0500 |
TT0500
Harness Lugs |
€0.80 |
Out-of-Stock
|
| TT 0501, RD 0786 |
103J1
TRIGGER SCREW |
€0.80 |
|
| TT 0502 |
10EZF
LEVER SHAFT BODY WASHER |
€0.80 |
Out-of-Stock
|
| TT 0504 |
10EWQ
PRE-PROGRAM KEY PIN |
€0.80 |
|
| TT 0505 |
1089E
PRE-PROGRAM KEY |
€4.00 |
Last items in stock
|
| TT 0506 |
1088X
PRE-PROGRAM SCREW |
€4.00 |
Last items in stock
|
| TT 0507 |
TT0507
Alert Plunger Assembly |
€0.80 |
Out-of-Stock
|
| TT 0509 |
10QK6
DRIVE GEAR (A) |
€15.00 |
Last items in stock
|
| TT 0510 |
109WT
DRIVE GEAR (B) |
€15.00 |
Last items in stock
|
| TT 0511 |
10D5T
DRIVE SHAFT |
€17.50 |
Last items in stock
|
| TT 0512 |
104LD
CROSS PIN (A) |
€0.80 |
|
| TT 0513 |
10N9J
PINION GEAR (B) |
€9.00 |
Last items in stock
|
| TT 0515 |
10MCT
CROSS PIN (B) |
€0.80 |
|
| TT 0516 |
TT0516
Alert Ratchet |
€0.80 |
Out-of-Stock
|
| TT 0518 |
10CCV
PRESSURE PLATE SPRING |
€0.80 |
|
| TT 0519 |
TT0519
Drag Plate |
€0.80 |
Out-of-Stock
|
| TT 0520 |
TT0520
Drag Washer Screws |
€0.80 |
Out-of-Stock
|
| TT 0521 |
10G11
DRAG WASHER |
€15.00 |
Last items in stock
|
| TT 0522 |
10EVT
PRESSURE PLATE |
€9.00 |
Last items in stock
|
| TT 0523 |
TT0523
Cooling Shield |
€0.80 |
Out-of-Stock
|
| TT 0524, TGT 0890 |
10EW9
WATERPROOF RING |
€0.80 |
|
| TT 0526 |
10PSW
STAND WASHER |
€0.80 |
|
| TT 0527 |
10NY8
STAND |
€4.00 |
Last items in stock
|
| TT 0528 |
10PV9
STAND SCREW |
€0.80 |
|
| TT 0529 |
10DAH
ANTI-REVERSE RATCHET |
€0.80 |
|
| TT 0530 |
10KNT
BEARING SPACER |
€0.80 |
|
| TT 0531, TGT 0729, RD 2110 |
103E9
SLIDER RETAINER SCREW |
€0.80 |
Out-of-Stock
|
| TT 0532 |
10KVD
SET PLATE |
€0.80 |
|
| TT 0533 |
10CBU
DOG SPRING |
€0.80 |
|
| TT 0534 |
10PKF
DOG |
€0.80 |
|
| TT 0535 |
TT0535
Left Side Plate |
€0.80 |
Out-of-Stock
|
| TT 0541 |
10CC4
LEVERSHAFT BODY |
€9.00 |
Last items in stock
|
| TT 0542 |
10HYH
PINION SHAFT |
€17.50 |
Last items in stock
|
| TT 0543 |
TT0543
Spool |
€0.80 |
Out-of-Stock
|
| TT 0544 |
TT0544
One-Piece Frame |
€0.80 |
Out-of-Stock
|
| TT 0575 |
10BMH
BALL BEARING(6.46G) MADE IN JAPAN |
€6.00 |
|
| TT 0581 |
10EYZ
O RING (A) |
€0.80 |
|
| TT 0601 |
10PRP
RIGHT SIDE PLATE SCREW |
€0.80 |
|
| TT 0701 |
10BC4
TRQS M3.5X20 |
€0.80 |
|
| TT 0766 |
TT0766
Right Side Plate (A) |
€0.80 |
Out-of-Stock
|
| TT 0805 |
TT0805
Rod Clamp Bolt / Nuts |
€0.80 |
Out-of-Stock
|
| TT 0806 |
TT0806
Rod Clamp Assembly |
€0.80 |
Out-of-Stock
|
