Parts for Shimano STELLA SW4000HGC (2020) reel

Shimano
PARTS-STLSW4000HGC
Find the part you need on the exploded view of the Shimano STELLA SW4000HGC (2020) reel, then order it directly from the list of available parts below.

Description

Identify the spare part(s) of the reel you need, then add them to the cart from the list of available spare parts located below the exploded view of the reel.

Exploded view of Shimano STELLA SW4000HGC (2020)

Product Details

Shimano Shimano
PARTS-STLSW4000HGC

Data sheet

Type
Spinning
Series
STELLA SW
Size
4000
Model
STLSW4000HGC
Generation
2020

Available parts for this reel

Old reference Reference Price (Tax Excl.)
RD 2110, TT 0531, TGT 0729 103E9
SLIDER RETAINER SCREW 		€0.80
Out-of-Stock
RD 3538 103NX
SPOOL SUPPORT 		€0.80
Out-of-Stock
RD 3561, TT 0632 10MT4
DRAG WASHER SCREW 		€0.80
RD 6008 10PN2
SET SCREW M2X5 		€0.80
RD 8013 10K40
01STLFW25S L/R SCREW 		€0.80
Out-of-Stock
RD 8059 10L9D
PROTECTOR SCREW 		€0.80
RD 8074 107F2
BEARING WATER PROOF 		€0.80
RD 8144 10ML2
BEARING RETAINER SCREW 		€0.80
RD 8759 106UX
02BBX3XT BAIL ARM CLICK 		€0.80
Out-of-Stock
RD 9833 107V2
04STL25 RATCHET SPR 		€0.80
Out-of-Stock
RD 9847 10CYU
04STL25 PRTCTR SRW A 		€0.80
Out-of-Stock
RD 9903 108WA
04STL25 O RING SS9.5 		€0.80
RD 9909 10BCP
01STLAR3000 EARED WASHER 		€0.80
RD 9912 10GEW
LEFT (SPOOL) BEARING LOCK 		€0.80
RD 9931 10CGZ
04STL1000 CLICK SPR 		€0.80
RD 9968 108W9
04STL10 O RING SS3.5 		€0.80
RD 10031 103NC
PAN P2X5 RP 		€0.80
Out-of-Stock
RD 10424 105BN
BALL BEARING MADE IN THAILAND 		€6.00
RD 10441 104JS
BALL BEARINGMADE IN THAILAND 		€6.00
RD 11018 10PDA
BALL BEARINGMADE IN THAILAND 		€6.00
RD 11646 107PS
07STL4 D/C RATCHET 		€0.80
RD 11663 104FW
07STL4 FRCTIN RING 		€0.80
RD 11706, TGT 1641 10KX1
BALL BEARINGMADE IN THAILAND 		€6.00
RD 12096 104Q6
BALL BEARINGMADE IN THAILAND 		€4.00
RD 13189 104PT
BALL BEARINGMADE IN THAILAND 		€4.00
RD 13317 10LAB
O RING NOK SS9 		€0.80
Out-of-Stock
RD 13381 104JT
BALL BEARINGMADE IN THAILAND 		€4.00
Out-of-Stock
RD 14259 10G6C
07CU3D AJST SPCR E 		€0.80
RD 14286 10MPF
TRS M2X3 RP 		€0.80
Out-of-Stock
RD 14300 10LTS
10STL4000 BRNG BUSH 		€0.80
RD 14780 10A6F
11BIO2500 D/C SCREW 		€0.80
RD 15488 10BBQ
12VQC3000 KEY WSR A 		€0.80
RD 15489 10BQE
12VQ2500S D/C SPRING 		€0.80
RD 15717 10BGE
13STLSW5HG S/C B W 		€0.80
RD 15718 1055G
13STLSW5HG SCREW 		€0.80
RD 15721 10A6N
13STLSW5HG S/C SRW B 		€0.80
RD 15722 10A6P
13STLSW5HG S/C SRW A 		€0.80
RD 15729 10HAF
13STLSW5HG O/P CVR 		€0.80
RD 15742 109UV
13STL-SW LINE BAND S 		€4.00
Out-of-Stock
RD 15991 1076P
13STLSW4XG N/L PLATE 		€0.80
RD 15992 1080X
13STLSW4XG ROTOR NUT 		€4.00
Out-of-Stock
RD 16380 10QBV
12SEPCI4+C3S KEY W B 		€4.00
RD 16426 103LB
TRS M2.6X4 SH RP 		€0.80
RD 16480 10JAB
14STL25 O RING SS015 		€0.80
RD 16607 104JV
BB 6X10X3 ARBN MADE IN JAPAN 		€6.00
Out-of-Stock
RD 16618 106VM
14STL4000 OSC PAWL 		€4.00
Out-of-Stock
RD 16740 10345
13BIOSW4XG DRAG W 		€4.00
Last items in stock
RD 16742 10C1A
13BIOSW4XG DRAG W B 		€4.00
Last items in stock
RD 16931 10B8N
14ARC5XG D/W RTNR 		€0.80
RD 16974 10LAD
09CH100D7 O RING SS3 		€0.80
RD 16996 10TNF
O RING SS4.5 		€0.80
RD 17028 10MHC
15TPSW5HG ROLLER CLUTCH WATER PROOF COV 		€0.80
RD 17030 10J2G
15TPSW5000HG ROTOR WASHER 		€0.80
Out-of-Stock
RD 17031 10667
95STL1CLCH INR S 		€4.00
Last items in stock
RD 17032 10QPK
15TPSW5000HG ROLLER CLUTCH ASSY 		€6.00
Out-of-Stock
RD 17033 108WZ
15TPSW5000HG O RING 		€0.80
RD 17467 10R2P
16VQ2500S BAIL SPRING 		€0.80
Out-of-Stock
RD 17468 10R2E
16VQ2500S BAIL SPRING GUIDE B 		€0.80
RD 17750 10TQH
16VQ4000HG BEARING HOUSING 		€0.80
RD 17751 10EX8
BALL BEARING MADE IN JAPAN 		€4.00
Last items in stock
RD 17752 10GHN
14OC200HG STR DRG BRNG WASHER 		€0.80
RD 18160 1020L
16EXSLBC3MXG BEARING SPACER 		€0.80
Out-of-Stock
RD 18448 101BJ
17EXSC3M LINE ROLLER SET 		€34.50
Out-of-Stock
RD 18711 10TJX
18STL2500 DRAG CLICK 		€0.80
Out-of-Stock
RD 18724 101D9
18STL2500 SPRING GUIDE A SUPPORT COLLA 		€0.80
RD 18726 10DKC
18STL2500 BAIL SPRING GUIDE A BUSH 		€0.80
Out-of-Stock
RD 18728 101D0
18STL2500 BAIL TRIP CAM BUSHING 		€0.80
Out-of-Stock
RD 18758 10TK0
SUS 4.05X5.8X0.1 		€0.80
Out-of-Stock
RD 18879 10DND
LH M2X3 RP 		€0.80
Out-of-Stock
RD 19029 101M1
18STL4000 ADJUSTING WASHER 0.2 		€0.80
RD 19224 1002S
18STL1SSSPG LINE ROLLER SUPPORT WASHER 		€0.80
Out-of-Stock
RD 19530 10DVA
19STLSW80HG HANDLE KNOB ASSY 		€38.00
Last items in stock
RD 19534 1015M
TRS M2.6X14.5 BH 		€0.80
Out-of-Stock
RD 19586 1015D
19STLSW80HG WORM BUSHING REAR 		€0.80
RD 19594 10E83
19STLSW80HG HANDLE KNOB SEAL 		€4.00
Last items in stock
RD 19615 10160
SPRING WASHER C5.25X6.5X0.05 		€0.80
Out-of-Stock
RD 19638 1015S
19STLSW10PG O RING 9.5 		€0.80
RD 19744 100XZ
04STL3 WORM SHAFT WASHER SET 		€4.00
RD 19745 104FH
HANDLE KNOB WASHER SET 		€0.80
RD 19747 101AV
95STL3000 SPOOL WASHER SET 		€4.00
RD 19754 10DKJ
98STL5H DRIVE GEAR WASHER SET 		€4.00
Last items in stock
RD 19857 10SAN
19VQ10SSSPG BAIL SPRING GUIDE A 		€0.80
RD 20436 100CW
TPGT WORM SHAFT PIN WASHER SET SPINNING 		€4.00
Out-of-Stock
RD 20473 1028J
20STLSW50HG DRIVE GEAR ASSY 		€39.10
Last items in stock
RD 20497 101NN
20STLSW50HG BEARING RETAINER 		€0.80
RD 20498 1028H
20STLSW50HG PINION GEAR 		€15.00
Last items in stock
RD 20504 10DVQ
20STLSW50HG HANDLE SCREW CAP 		€15.00
Last items in stock
RD 20505 101N9
20STLSW50HG OSCILLATING GUIDE 		€0.80
RD 20507 101NW
20STLSW50HG OSCILLATING SLIDER BUSHING 		€0.80
RD 20508 101N2
20STLSW50HG IDLE GEAR 		€6.00
Last items in stock
RD 20511 101NM
20STLSW50HG BEARING WATER PROOF 		€0.80
RD 20512 101NX
20STLSW50HG BODY SEAL 		€0.80
RD 20518 101MT
20STLSW50HG IDLE GEAR B SHAFT 		€0.80
RD 20519 101NQ
20STLSW50HG IDLE GEAR (LARGE) 		€6.00
Last items in stock
RD 20520 101NK
20STLSW50HG WORM SHAFT RETAINER 		€0.80
RD 20521 10E3E
20STLSW50HG REAR PROTECTOR 		€9.00
Out-of-Stock
RD 20523 1028T
20STLSW50HG IDLE GEAR B (SMALL) 		€6.00
Last items in stock
RD 20524 101P0
20STLSW50HG BUSHING (PINION GEAR) (REAR) 		€0.80
RD 20528 1028S
20STLSW50HG ROLLER CLUTCH INNER WASHER 		€0.80
RD 20558 10RTD
20STLSW50HG SIDE COVER ASSY 		€34.50
Last items in stock
RD 20560 10RTA
20STLSW50HG HANDLE SHAFT COVER ASSY 		€27.50
Out-of-Stock
RD 20561 10RR7
20STLSW50HG ROLLER CLUTCH WATERPROOF SET 		€9.00
Last items in stock
RD 20617 10E8M
TRS M2.6X4 NL RP 		€0.80
Out-of-Stock
RD 20663 10RZ1
20STLSW50HG REAR PROTECTOR SCREW D 		€0.80
RD 20746 10THQ
20STLSW40XG DRAG KNOB ASSY 		€34.50
Last items in stock
RD 20748 100NP
20STLSW40XG ROTOR ASSY 		€54.00
Last items in stock
RD 20749 100NN
20STLSW40XG BAIL ASSY 		€32.50
Last items in stock
RD 20751 100NS
20STLSW40XG MAIN SHAFT ASSY 		€20.00
Out-of-Stock
RD 20752 100HM
20STLSW40XG HANDLE SHANK ASSY 		☹ This part is not produced anymore
RD 20761 10EA2
20STLSW40XG BAIL ARM 		€4.00
RD 20763 10RKV
20STLSW40XG LINE ROLLER SUPPORT 		€4.00
RD 20764 10EA0
20STLSW40XG BAIL SPRING COVER 		€6.00
Last items in stock
RD 20765 10RF8
20STLSW40XG BAIL HOLD SUPPORT GUARD 		€6.00
Last items in stock
RD 20768 10E2E
20STLSW40XG BAIL TRIP LEVER 		€0.80
RD 20769 10RLC
20STLSW40XG MAIN SHAFT SPACER 		€4.00
Out-of-Stock
RD 20771 10EA4
20STLSW40XG ROTOR BRIM 		€4.00
Last items in stock
RD 20773 10E24
20STLSW40XG BAIL TRIP STRIKE 		€0.80
Out-of-Stock
RD 20774 10SQD
20STLSW40XG WORM SHAFT 		€4.00
RD 20775 10RMA
20STLSW40XG BAIL ARM SCREW 		€4.00
RD 20776 10RGB
20STLSW40XG BAIL HOLD SUPPORT SCREW 		€4.00
Out-of-Stock
RD 20779 10RF0
20STLSW40XG ROTOR GUARD A 		€0.80
RD 20780 10EA5
20STLSW40XG ROTOR GUARD (B) 		€0.80
RD 20782 100YU
20STLSW40HG SPOOL ASSY 		€117.00
Last items in stock
RD 20783 10T8D
20STLSW40HG BODY ASSY 		€55.80
Last items in stock
RD 20784 100YZ
20STLSW40HG HANDLE ASSY 		€86.40
Last items in stock
RD 20785 1055D
LH M2X4 RP 		€0.80
RD 22803 145QR
21EXSC30M_DRAG WASHERS RETAINER NEW 		€0.80
