Parts for Shimano SARAGOSA 5000F (2008) reel

Shimano
PARTS-SRG5000F
Find the part you need on the exploded view of the Shimano SARAGOSA 5000F (2008) reel, then order it directly from the list of available parts below.

Description

Identify the spare part(s) of the reel you need, then add them to the cart from the list of available spare parts located below the exploded view of the reel.

Exploded view of Shimano SARAGOSA 5000F (2008)

Product Details

Shimano Shimano
PARTS-SRG5000F

Data sheet

Type
Spinning
Series
SARAGOSA
Size
5000
Model
SRG5000F
Generation
2008

Available parts for this reel

Old reference Reference Price (Tax Excl.)
RD 0521 RD0521
Rotor Nut 		€0.80
Out-of-Stock
RD 0743 10HHL
SL2OSCILLAITING SLIDERW 9X13X0.1 		€0.80
Out-of-Stock
RD 0806 RD0806
Screw 		€0.80
Out-of-Stock
RD 0998 RD0998
Screw 		€0.80
Out-of-Stock
RD 1109 RD1109
Screw 		€0.80
Out-of-Stock
RD 3503 10BXK
STL1000 SPOOL WASHER 		€0.80
RD 4362 RD4362
Screw 		€0.80
Out-of-Stock
RD 4416 RD4416
Screw 		€0.80
Out-of-Stock
RD 4649 RD4649
Spacer 		€0.80
Out-of-Stock
RD 5447 RD5447
Roller Clutch Assembly 		€0.80
Out-of-Stock
RD 5449 RD5449
Anti-Reverse Cam 		€0.80
Out-of-Stock
RD 5823 RD5823
Lever Spring Guide A 		€0.80
Out-of-Stock
RD 5825 RD5825
Lever Spring Guide B 		€0.80
Out-of-Stock
RD 6283 RD6283
Screw 		€0.80
Out-of-Stock
RD 6379 RD6379
Screw 		€0.80
Out-of-Stock
RD 6380 RD6380
Bail Spring Guide A 		€0.80
Out-of-Stock
RD 6383 RD6383
Bail Spring Guide B 		€0.80
Out-of-Stock
RD 6539 RD6539
Bail Trip Lever 		€0.80
Out-of-Stock
RD 6639 RD6639
Screw 		€0.80
Out-of-Stock
RD 6692 RD6692
Bail Hold Support Shaft 		€0.80
Out-of-Stock
RD 6760 RD6760
Bail Spring Guide A Collar 		€0.80
Out-of-Stock
RD 6761 RD6761
Bail Spring 		€0.80
Out-of-Stock
RD 6765 RD6765
Bail Hold Support Spacer 		€0.80
Out-of-Stock
RD 6767 RD6767
Bail Trip Lever Spring 		€0.80
Out-of-Stock
RD 6770 RD6770
Bushing 		€0.80
Out-of-Stock
RD 6776 RD6776
Oscillating Gear Bushing 		€0.80
Out-of-Stock
RD 6843 RD6843
Friction Ring 		€0.80
Out-of-Stock
RD 7561 RD7561
Main Shaft 		€0.80
Out-of-Stock
RD 7563 RD7563
Oscillating Slider Inner 		€0.80
Out-of-Stock
RD 7577 RD7577
Screw 		€0.80
Out-of-Stock
RD 7926 103HN
LINE ROLLER SCREW 		€0.80
Out-of-Stock
RD 8695 RD8695
Oscillating Slider 		€0.80
Out-of-Stock
RD 8696 RD8696
Oscillating Gear 		€0.80
Out-of-Stock
RD 10388 RD10388
Spool Support 		€0.80
Out-of-Stock
RD 10420 RD10420
Bearing Spacer 		€0.80
Out-of-Stock
RD 10421 RD10421
Line Roller Collar 		€0.80
Out-of-Stock
RD 10422 RD10422
Line Roller 		€0.80
Out-of-Stock
RD 10423 RD10423
Line Roller Bushing 		€0.80
Out-of-Stock
RD 10424 105BN
BALL BEARING MADE IN THAILAND 		€6.00
RD 10463 10BGC
BALL BEARING MADE IN JAPAN 		€6.00
RD 11166 RD11166
Spacer 		€0.80
Out-of-Stock
RD 11344 RD11344
Trip Lever Washer 		€0.80
Out-of-Stock
RD 12000 RD12000
Handle Screw Cap 		€0.80
Out-of-Stock
RD 12024 RD12024
Line Roller Washer 		€0.80
Out-of-Stock
RD 12028 RD12028
Line Roller Support 		€0.80
Out-of-Stock
RD 12038 RD12038
Drag Knob 		€0.80
Out-of-Stock
RD 12039 RD12039
Spool Assembly 		€0.80
Out-of-Stock
RD 12040 RD12040
Bail Spring Cover 		€0.80
Out-of-Stock
RD 12041 RD12041
Bail Arm 		€0.80
Out-of-Stock
RD 12042 RD12042
Bail Spring Cover Guard 		€0.80
Out-of-Stock
RD 12043 RD12043
Rotor 		€0.80
Out-of-Stock
RD 12044 RD12044
Bail Assembly 		€0.80
Out-of-Stock
RD 12045 RD12045
Pinion Gear 		€0.80
Out-of-Stock
RD 12046 RD12046
Anti-Reverse Lever Cover 		€0.80
Out-of-Stock
RD 12047 RD12047
Side Cover Flange 		€0.80
Out-of-Stock
RD 12048 RD12048
Drive Gear 		€0.80
Out-of-Stock
RD 12049 RD12049
Side Cover 		€0.80
Out-of-Stock
RD 12050 RD12050
Handle Assembly 		€0.80
Out-of-Stock
RD 12051 RD12051
Body 		€0.80
Out-of-Stock
